Measuring current

A current
DC
A
AC
A
AC+DC
current
TRMS
Note
Note
50,000-count Benchtop Multimeter
(cont.)
In "DC" mode, users can measure a direct current value or an alternating
current's direct component.
Rate
500 µA 0.2% + 5D
5 mA 0.2% + 3D
50 mA 0.2% + 3D
500 mA 0.2% + 5D
10 A 0.5% + 5D
In "AC" and "AC+DC" modes, users can measure an alternating current's rms
,
value with/without its direct component (no capacitive coupling in "DC" mode).
Rate Precision
500 µA 0.5% + 30D
5 mA 0.5% + 30D
50 mA 0.5% + 30D
500 mA 0.5% + 30D
10 A 2.5% + 30D
Results < 0.2 % are not displayed.
500 µA
5 mA
50 mA
500 mA
10 A
Specifications for direct current superimposed on a sinusoidal signal in the
40 Hz to 10 kHz band, valid from 10 to 100 % of rate.
For the mA and µA range, the "AUTO PK" mode is always active:
Additional error of 2 % for a peak factor between 1 and 1.5.
Additional error of 15 % for a peak factor between 1.5 and 2.
Peak factor is 5 for a 10 A range.
In 500 mA and 500 mA
DC
Voltage drop
Protection
Fuse
In 10 A and 10 A
AC
Voltage drop
Protection
Fuse
Fuse can be accessed outside unit.
Precision Resolution
10 nA
0.1 µA
1.0 µA
10.0 µA
1 mA
Resolution
10 nA
0.1 µA
1.0 µA
10.0 µA
1 mA
40 Hz to 1 kHz
10 nA
0.5% + 40 D
0.1 µA
1.0 µA
0.5%
10 µA
+ 30 D
1 mA
:
AC+DC
< 600 mV
600 Vrms per HPC ceramic-type fuse
600 V / 10 A / 50 kA Cos ϕ > 0.9 (6.3 x 32 mm)
(or ):
AC+DC
< 300 mV
600 Vrms per HPC ceramic-type fuse
600 V / 10 A / 50 kA, Cos ϕ > 0.9 (6.3 x 32 mm)
Input Admissible
resistance overload
about 350 Ω
about 35 Ω
20 Arms
about 5 Ω
(30 s max.)
about 0.5 Ω
about 0.02 Ω
Input Admissible
resistance overload
about 350 Ω
about 35 Ω
20 Arms
about 5 Ω
(30 s max.)
about 0.5 Ω
about 0.02 Ω
Accuracy
1 to 4 kHz 4 to 10 kHz
typ.1%+ 40 D
1%
+ 30 D + 30 D
-
-
2%
-
49
