Informations concernant le RS-422 destinées aux développeurs
bit 7 bit 6
Byte 0 0 0
Byte 1 Standby 0
Servo
Byte 2 0
Lock
Auto
Byte 3 0
Mode
Byte 4 Select EE Full EE
Byte 5 0 0
Byte 6 0 Lamp Still
Byte 7 0 0
Byte 8 0 0
Byte 9 0 0
Variables
Cassette Out
Local
Standby
Direction
Still
Auto Mode
Select EE, Full EE
Lamp Still/Fwd/Rev
Near EOT
EOT
Others
Cue Complete (byte 2, bit 0)
HyperDeck Serial RS-422 Protocol
Protocole Based on Sony 9-pin protocol
Interface Baud rate
1 start bit
8 data bits
1 stop bit
1 parity bit
Odd parity
bit 5 bit 4 bit 3
Cassette
0 0
out
Stop 0 Rewind
Shuttle Jog Var
0 0 Aout Set
0 0 0
0 0 0
Lamp Fwd Lamp Rev 0
0 0 0
Near EOT EOT 0
0 0 0
Set if no SSD is present
Set if Remote is disabled (local control)
Set if a disk is available
Clear if playback is forwarding, set if playback is reversing
Set if playback is paused, or if in input preview mode
Set if in Auto Mode
Set if in input preview mode
Set according to playback speed and direction
Set if total space left on available SSDs is less than 3 minutes
Set if total space left on available SSDs is less than 30 seconds
Always 1: Cue requests are always instantaneous
38.4 Kbps
bit 2 bit 1 bit 0
0 0 Local
Forward Record Play
Direction Still 1
Ain Set Out Set In Set
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
Port RS-422 140 140
