Use sharp blades only!
03/2013
ECO-STRIPPER, #013993
Messerbreite
1
6 5 4 3 2
5.2 Use
The ECO-STRIPPER removes bonded, flexible floor coverings
in strips. It uses an oscillating system, i.e. the blade performs a
circular movement. This movement results in a lateral cutting.
This could make the stripper swing sideways if you want to
remove stiff flooring or aggressive adhesive. In this case using
the device may be limited due to its system. Before starting
work, the flooring needs to be cut into strips of the blade's width.
To begin cut one strip crosswise. Then lift the flooring slightly in
order to get the blade underneath it. We recommend to cut the
first strip at right angles to the main working direction. By so
doing access to the next strips is made easier. Cut the strips
smaller if the floor covering is bonded very securely, e.g. with an
epoxy adhesive.
The blades are sharpened by the floor pavement. Therefore the
blade has to be changed only if it is twisted or becomes worn.
6.0 Information about certain floor coverings
Main applications of the ECO-STRIPPER are carpets with
foam backing, CV-floorings, PVC-floorings and light car-
pets.
CV-floorings, PVC-floorings and carpets without foam
backing:
Cut stripes according to the blade width. Check from time
to time if the blade is straight.
Carpets with foam backing:
Remove upper layer with carpet clamp. Remove the foam
backing with the STRIPPER. Remove foam across the
width if you have an uneven sub-floor.
Semi-flexible tiles:
These tiles can be removed without pre-cutting, if they
are not bonded extremely tight.
7.0 Trouble shooting
Trouble
Eventual cause
Machine does not work
Power supply
Disconnected
Blown fuse
Defective cable or plug
Undue force necessary
Blade is blunt
or excessive vibration
Excessive vibration
Expendable parts are
worn out
Elimination
Have machine
repaired by a qualified
electrician
resp. change parts
Change blade
Return machine for
service and/or repair
12
