Section 7: DualSelect
7.1

System Controls - Front of System

Shield (closed position)
The shield must be closed to
receive fluid from bottle "A" or "B."
• Opening the shield relieves bottle
air pressure and allows removal
or replacement of bottles. Selector
knob should be in "Open•H
position when removing bottles.
Bottle "A"
Selector knob
• Selects between Bottles "A" and
"B", and "Open • H2O" which is
external office water supply.
7.2

Connections - Back of System

Air (in)
Connect
DualSelect™
air line (gray) to
office air supply.
Air (out)
Connect Scaler/JET
air line to this port.
NOTE: For closed line option, remove DualSelect
ENGLISH • 5
System Component Description
O"
2
Cap
external office water supply.
water line completely.
Bottle "B"
H
O (in)
2
Connect
DualSelect™
water line (blue) to
Lavage (out)
Connect Scaler/JET
water line to this port.
