Klipsch REFERENCE R-4B Mode D'emploi page 8

DUAL RCA TO DUAL RCA ANALOG CONNECTION
CONNEXION ANALOGIQUE DOUBLE FICHE RCA VERS DOUBLE FICHE RCA • CONEXIÓN ANALÓGICA DE DOS RCA A DOS RCA • ANALOGVERBINDUNG (DOPPEL-CINCH ZU DOPPEL-CINCH) •
CONNESSIONE ANALOGICA DA DOPPIO JACK RCA A DOPPIO JACK RCA • CONEXÃO ANALÓGICA DE RCA DUPLO PARA RCA DUPLO • 双 RCA 转双 RCA 模拟连接
Small Yellow Tip
TV
Small Yellow Tip
Petit embout jaune
Punta pequeña amarilla
Kleine gelbe Spitze
Punta gialla piccola
Ponta amarela pequena
黄色细端
7
Soundbar
3
4
(IF TV DOESN'T HAVE DUAL RCA OUT SEE NEXT PAGE)
1
DUAL RCA CABLE
NOT INCLUDED
TV
Audio Out
R
2
L
