3. Press in the direction of the
arrow (a) until locking tab (C)
clicks into place.
4. Shake the PX4D lightly to ver-
ify that it does not fall off.
Removal
1. Press the strap holder locking
tab (C) in the direction of ar-
row (b) to release the lock.
2. With the lock released, slide
the PX4D in the opposite direc-
tion from when attaching it, and
remove it from the holder.
a

Controls and connectors

1
2
C
3
4
5
6
7
8
1. Control knobs
These knobs control the gain, tone, and volume
b
of the amp models and synth parameters.
2. LCD (Liquid Crystal Display)
3. TUNE/BYPASS button
4. EXIT button
This button returns you back to Play mode from
any mode.
17
16
15
14
13
9 10 11 12
9
