- Page 1 LX Notebook Tray User's Guide Guía del usuario Manuel de l’utilisateur Benutzerhandbuch Gebruikersgids Guida per l’utente ユーザーガイド 2.5 - 12 lbs (1.1 - 5.4 kg) M4 x 10mm M4 x 10mm M3 x 6mm 888-97-088-W-00 rev.B • 01/10 1 of 8...
- Page 2 Set Your Workstation to Work For YOU! Confi gure su estación de trabajo para que trabaje para USTED. Ajustez votre station de travail en fonction de VOS besoins ! Richten Sie Ihren Arbeitsplatz so ein, dass er für SIE arbeitet! Stel uw werkstation zo in dat het voor U werkt! Approntare la stazione di lavoro nella posizione ergonomica ottimale.
- Page 3 Attach portrait/landscape rotation stop screw Acoplar tornillo tope de rotación vertical/horizontal Fixez la vis de rotation verticale/horizontale Anbringen der Stopschraube für die Portrait-/Landschaftsrotation. M3 x 6mm Staande/liggende draaistopschroef aansluiten Fissare la vite di arresto sulla posizione ritratto/paesaggio M4 x 10mm M4 x 10mm Place Notebook Place docking station and notebook...
- Page 4 Place Notebook Colocar portátil Placez l’ordinateur portable Colocar o portátil Notebook platzieren Notebook plaatsen Collocare il portatile Pa ds will help prevent notebook from slipping, but they will not hold all notebooks on the tray in all circumstances. Use caution while tilting the tray, since some angles may cause the notebook to fall off resulting in equipment damage or personal injury.
- Page 5 Place docking station and notebook Colocar plataforma de fi jación y portátil Placez la station d’accueil et l’ordinateur portable Platzieren der Docking-Station und des Notebooks. Dockstation en notebook plaatsen Collocare la base e il portatile 888-97-088-W-00 rev.B • 01/10 5 of 8...
- Page 6 Adjustment Ajuste Einstellung Regolazione 調整 Réglage Instellen It is important that you adjust this product according to the weight of the mounted equipment as described in the following steps. Any time equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure safe and optimum operation.
- Page 7 Lift – Up and down Follow these instructions to tighten or loosen tension. Elevación (arriba y abajo) Siga estas instrucciones para ajustar o afl ojar la tensión. Ajustement en hauteur : bas et haut Suivez ces instructions pour desserrer ou resserrer la tension. Höhenverstellung –...
- Page 8 888-97-088-W-00 rev.B • 01/10 8 of 8...
