DESCRIPTION

The "Cartridge II" is a control tool designed to help user controlling radio broadcast softwares easily
and efficiently.
Thanks to RS232 simplicity, MIDI flexibility and the IP power, Cartridge II allows to send "start" orders
to 3 different communication channels.
Embedded web browser is used for each channel setting, and to choose the link type. The software
feedback allows to switch on lights, providing a full display of the start state.
Associated with a broadcasting software, "Cartridge II" is a simple but efficient alternative to both
"keyboard and mouse".

BLOCK DIAGRAM

Keyboard
POWER
SUPPLY
+12V
RAMI
µC
INTERFACE CONTROL
&
PROTOCOL GENERATION
RS 232
INTERFACE
ETHERNET
CONTROLLER
14
USB
Female
Sub-D 9pts
RS232
RJ45
Cartridge II
