Cameo ROOT PAR 4 Manuel D'utilisation page 7

12
The CLROOTPAR4 and CLROOTPAR6 models feature identical connections, operating and display elements.
MIC
8
Microphone for music-control mode.
TILT
9
Knurled screw for the TILT feature for uplighting. For a more discreet look, the installation double bracket can be removed.
RUBBER FEET
10
Four rubber feet for good stability.
SECURING LUG
11
Securing lug for attaching the spotlight for truss installations.
HANDLE SCREWS
12
The two handle screws are for adjusting and fixing the stand and/or mounting bracket.
PORT FOR W-DMX™ CONNECTION
The USB-A port for the optional iDMX stick is located on the panel on the opposite side of the spotlight.
9
10
8
6
7
10
10
MIC
5
11
10
12
7
