Part Identification; Transmitter Battery Installation - iKarus 6811003 Manuel D'utilisation

Transmitter
Power
Indicator
Throttle stick
Power
switch
Band
selector
Helicopter
Main rotor
Fuselage
ON / OFF
switch
OFF
CHA
ON
Charge socket
1.
1. Use a screwdriver to loosen the screws on the battery compartment by turning the
screw counter-clockwise.
2. Insert 6 AA size batteries into the battery compartment.
3. Close the battery cover, then tighten the screws by turning them clockwise.

Part Identification

Direction stick
Trimmer
Charging indicator
Cover and
charging wire

Transmitter Battery Installation

2.
Stabilizer
Main shaft
Main gear
Landing gear
14
1 x Spare Tail Propeller
Tail rotor
3.
