Connection

0 ,
Remove the terminal area covers from Module A and Module B.
Always check whether the connector of the vehicle battery (battery I) on
Module A has been separated by pulling out the feed plug! The feed plug
connects the Module A with the contacts 9 and 13 to the 13-pole coupling plug.
(See also MES Module A operating instructions, page 13, picture 8, pos. 1).
