Module B
1 2 3
# $%
1 Feet and mounting
2 Bore-holes for plastic rivets
3 9-pole multipoint connector
4 8-pole multipoint connector

Technical data

Power supply: using MES Module A
Charging Charging current with MES 250-(1-4) / Module A max. 16 A,
current mains: Charging current with MES 400-(1-4) / Module A max. 27 A,
arithmetic average, electronically controlled according to the
charging characteristic curve IUoU.
Voltage mains:
Direct voltage 12 V
28
Lerchenfeldstr. 9 87600 Kaufbeuren Tel.: 049 (0)8341 9764-0 Fax: 049 (0)8341 67806
4 5 6 7
5 Terminal area cover
6 Threaded bolts for protective
conductor contact
7 Terminal area cover lock.
on battery
