6. PROGRAMMING BUTTONS AND INDICATOR LEDS
SEL button: selects the type of function to store in the memory; selection is indicated by the LED flashing. The
desired function can be selected by pressing the button repeatedly. The selected function remains active for
15 seconds (flashing LED), after which the control unit returns to its original status.
SET button: programmes the function that has been selected using the SEL. button.
Indicator LEDs
LED lit: option stored.
LED off: option not stored.
LED flashing: option selecte.
Reference Led
1) CODE
2) CODE SENS.
3) T. MOT.
4) WIND SPEED
5) SUN SENSOR
6) RAIN SENSOR
7) SUN
8) RAIN
MAIN MEN
Led off
No code
No code
Motor running time 2 minutes
Wind safety 25 km/h
Sun sensor = OFF
Rain sensor = OFF
Presence of sunlight = No
Presence of rain = No
Led on
TX Pgm code
Sensor code pgm.
Motor running time Pgm.
Wind safety Pgm.
Sun sensor = ON
Rain sensor = ON
Presence of sunlight = Yes
Presence of rain = Yes
