6.5.1.1 Using the Company Card to set the TPS
code
1. Check to ensure that no battery is in the charger.
2. Plug the appliance's supply cord into the power
outlet.
3. Hold the Company Card against the lock symbol
on the appliance within one minute. The yellow
TPS LED blinks rapidly (programming mode).
4. Remove the Company Card from the lock symbol.
5. End the code setting operation by unplugging the
supply cord from the power outlet and waiting
until the green lamp on the charger goes out.
NOTE This may take several seconds.
6.5.1.2 Using the Company Card to cancel the
code
1. Check to ensure that no battery is in the charger.
2. Plug the appliance's supply cord into the power
outlet. The yellow lamp blinks slowly.
3. Hold the Company Card against the lock symbol
on the appliance within one minute (please refer
to the operating instructions for the appliance for
the position of the lock symbol). The yellow TPS
lamp blinks rapidly.
4. Remove the Company Card from the lock symbol.
5. Hold the Company Card against the lock symbol
on the appliance again. The yellow lamp goes out
and the theft protection code is cancelled.
6. End the code cancelling operation by unplugging
the supply cord from the power outlet and waiting
until the green lamp on the charger goes out.
NOTE This may take several seconds.
6.5.2 Activation of the theft protection system
for the battery
6.5.2.1 Using the Company Card to activate the
TPS battery theft protection system
1. Check to ensure that no battery is in the charger.
2. Plug the appliance's supply cord into the power
outlet.
3. Hold the Company Card against the lock symbol
on the appliance within one minute. The yellow
TPS lamp blinks rapidly.
4. Remove the Company Card from the lock symbol.
5. Depending on the type of Hilti battery, push or
slide the battery into the interface provided. The
charging operation doesn't begin.
6. Press the TPS battery activation button on the
charger. The yellow TPS battery lamp on the
charger lights.
7. Remove the battery from the charger.
8. Repeat steps 5 to 7 according to the number of
batteries in which the code is to be set.
9. End the code setting operation by unplugging the
supply cord from the power outlet and waiting
until the green LED on the charger goes out.
NOTE This may take several seconds.
10. The batteries can now be charged as usual in any
Hilti charger for Li ion batteries with TPS and the
corresponding code.
6.5.2.2 Using the Company Card to cancel the
TPS theft protection code in the battery
1. Check to ensure that no battery is in the charger.
2. Plug the appliance's supply cord into the power
outlet.
3. Hold the Company Card against the lock symbol
on the appliance within one minute. The yellow
TPS lamp blinks rapidly.
4. Remove the Company Card from the lock symbol.
5. Depending on the type of Hilti battery, push or
slide the battery into the interface provided. The
charging operation doesn't begin. The yellow TPS
battery lamp lights.
6. Press the TPS battery activation button on the
charger. The yellow TPS battery lamp on the
charger goes out.
7. Remove the battery from the charger.
8. Repeat steps 5 to 7 according to the number of
batteries in which the code is to be cancelled.
9. End the code cancelling operation by unplugging
the supply cord from the power outlet and waiting
until the green LED on the charger goes out.
NOTE This may take several seconds.
10. The batteries can now be charged as usual in any
Hilti charger for Li ion batteries.
6.5.3 Before use
1. Plug the appliance's supply cord into the power
outlet. The yellow theft protection LED blinks. The
appliance is then ready to receive the signal from
the activation key.
