4 Usage

4.1 Safety information

CAUTION!
Overloading the bath lift can lead to damage to
the device or prevent lifting.
– Do not overload the bath lift and observe the
specifications on the identification label and in
section 9.1 Dimensions and weight, page 24
with regard to its load capacity.
CAUTION!
Danger of pinching fingers
– Do not insert fingers into the guide between
the seat plate and the backrest.
– Do not reach under the seat plate or between
the lifting scissors.
IMPORTANT!
Moisture may penetrate into a damaged hand
control, which could lead to a short circuit and
fire.
– Always perform a visual inspection of the
product for external damage before each use.
– If the housing of the hand control is damaged
or shows cracks, do not use the hand control.
– Recharge the battery completely before each
use, 3.4 Charging the battery, page 13.
1. Refer to operating conditions in section 9.4
Environmental Parameters, page 25.
1574470-D

4.2 Controlling the bath lift

The bath lift can be moved in the following directions:
The bath lift is controlled via the hand control, either by
the user or an assistant.
With a fully charged battery, the Aquatec® R and F
can perform 5 bathing operations with a load of 140
kg. The XL can perform 4 bathing operations with a
load of 170 kg.
E
D
IMPORTANT!
Risk of damage
– The hand control may only be used when the
backrest is properly installed and in the upright
position.
A
B
C
Usage
15
