When the bowl is full raise the end of the drain pipe to a height higher than the
top of the appliance to stop the flow of water. Empty and replace the bowl and
continue draining the machine until empty.
4. Once the machine is fully drained of water, clip the hose to the rear of the
machine. Press the Porte button and remove the load.
The door can be opened approximately 2 minutes after the power failure by simply
pressing the door button. Do not force open the door.
Important: the water and the load may be very hot!
•
Max. load of dry laundry
•
Water pressure
•
Spin speed
Measurements
•
Width
•
Depth
•
Height
NB: For specifications regarding electrical data, see the data plate on the front of
the washing machine (door area). You will also need to refer to the information on
the data plate should you need to contact Service for any advice.
11:43
Page 33
Technical data
max: 1200 rpm (HF7 12 I)
max: 1400 rpm (HF7 14 I)
max: 1600 rpm (HF7 16 I)
33
7kg
(0.5-8 bar)
0.05-0.8 MPa
59,5cm
65cm
85cm
