ECOFOREST NETFLAME MXS 00-02 Manuel D'utilisation page 33

Top plate of the fireplace.

Heat exchanger.

IMPORTANT: If the stove is operating while full of ash or residues, that might stretch the burn pot and its
support, the ash box and even the burn pot, being the cause of bad operation or possible breakdown.
This is necessary to ensure correct operation and maintain the stove's life duration. When winter ends,
contact your provider (if he did not contact you) and meet to carry out this maintenance; the following shall be done
(the stove must always be disconnected from power):
5.6. Opening the sides. CAUTION! (WE MUST UNPLUG THE STOVE BEFORE PERFORMING THIS OPERATION).
Remove the screws holding the side doors.
5.7. Review of the daily and weekly cleaning outlets.
5.8. Cleaning outlets. The cleaning outlet lids are marked in red.
You must remove the side outlets, enter the wire brush and move it through the entire surface in order to
remove all the ash attached to the walls of the gas chamber. This operation must also be performed with the
front cleaning outlet.
As indicated in drawing you can access to the lateral and lower cleaning outlet, which must be thoroughly
cleaned, since the correct operation of the stove will depend on its cleaning.
In the case of the lateral outlets, you must be aware that there is one on each side of the stove, in addition to
the core outlet located under the ash box.
Forro frontal-top.

Lateral cleaning outlets.

It is recommendable to calculate the frequency with which you clean the outlet cleaning considering the
hours of operation, thus avoiding ash saturation.
MAINTENANCE AT END OF SEASON OR EVERY 500 KG OF FUEL.
32
Drawing 14
Drawing 15
