7. Remove cable for the level indicator (7).
8. Loosen hose clamp (8) and remove steam hose (9).
9. Remove electrode plugs (10) and (11).
10. Remove cotter pins (12) and (13).
11. Push up and remove the steam cylinder (14).
12. Rinse the steam cylinder (14) using tap water.
13. Clean water inlet valve (15) and water outlet valve (16)
and check for correct functioning
9
7
10
12
13
14
16
15
M+P-26A-1022
14. Remove drain filter (17) from the cylinder base (18) and
rinse using tap water.
Replace O-ring of the drain filter (17) if necessary.
15. The drain filter (17) and the steam cylinder (14) must be
installed in reversed order.
14
18
17
M+P-26A-1023
