3.2. ELEMENTS OF THE DIGITAL DISPLAY
Symbol
A1
A2
A3
A4
A5
Gala Gar, S.L. c/ Jaime Ferrán, 19 (Políg. Cogullada) | Tel.: (+34) 976 47 34 10 - 50014 ZARAGOZA |
Description of operation.
Wire diameter (mm) selected for MIG welding. Options
vary according to material and gas selected.
Set by pressing P1 .
Display of welding voltage (arc length) actual and setting in volts
In synergic mode , when adjusting with E1, the correction is briefly displayed in volts
Then the total voltage is displayed again in volts
Supply voltage. Illuminates 110V/120V or 220V/230V depending on the connected voltage.
Selected material and gas for MIG welding.
Set by pressing P2 .
MIG cycle control, torch
pulse mode.
Set by pressing P4 .
Fe+CO2
Fe+MIX
FLUX
SS+MIX
AL+Ar
Cu+Ar
2T: 2-stroke. Welding starts when the torch trigger is pressed and
stops when the trigger is released. Useful for short welds.
4T: 4 strokes. Welding starts when the trigger is pulled, continues
when the trigger is released and stops when the trigger is pulled and
released the next time. Useful for long welds.
SPOT: spot welding. Each torch pulse generates one spot weld. The
time is defined in the function
22/64
Fe+CO2
Fe+MIX
FLUX
SS+MIX
AL+Ar
Cu+Ar
.
.
Steel
Steel
Steel
Stainless
Aluminium
Copper
which is set with P5
www.galagar.com
0.6/0.8/1.0 mm
0.6/0.8/1.0 mm
0.8/1.0 mm
0.8/1.0 mm
1.0/1.2 mm
1.0 mm
.
100% CO
2
CO +Argon mixture
2
No gas.
CO +Argon mixture
2
100% Argon
100% Argon
and E2.
