Dear MAGNAT Customer,
The RX 22 car hi-fi power amplifier will enable you to satisfy your high demands on sound reproduction in your
car. With its impressive deep-bass power reserves, low harmonic content and neutral reproduction, the RX 22
takes car hi-fi to new heights. The amplifier is characterized by low operating current, rapid switching capabilities
and excellent temperature stability. Experience and enjoy how this high-tech machine perfectly reproduces
magnificent sound.
Please read all of the owner's manual before installing and using the amplifier.
1.
TECHNICAL DATA
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 342, B+=14.4V)
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 342, B+=14.4V)
Loudspeaker impedance (stereo)
Frequency response
Total harmonic content (DIN 45 403)
Stereo separation (IEC 581 )
Weighted noise distance (IEC A)
Input sensitivity LOW LEVEL INPUT
Input impedance LOW LEVEL INPUT
Low-pass filter
High-pass filter
Bass boost
Subsonic filter
Supply
Fuse
Sizes (W x H x D)
Weight
SUBJECT TO TECHNICAL CHANGE
2.
FEATURES
·
Complementary push-pull final stage
·
Automatic switching on/off via car radio
·
Infinitely adjustable low-pass filter 40 – 300 Hz
·
Infinitely adjustable high-pass filter 40 – 300 Hz
·
Infinitely variable bass equalisation
·
Subsonic filter 15 Hz
·
Adjustable input sensitivity
·
Bridgeable 2-/1-channel mode
·
Tri-mode
·
Channel mode selector switch
·
Electronic protective circuit against short circuiting, DC offset and excess temperature
·
Mute switch for suppressing switch-on crackle interference
·
Capsulated loudspeaker and power-supply screw terminals
·
Low-level outputs (cinch jacks) for connecting additional amplifiers
·
Status indicator (green LED) and overload indicator (red LED)
·
Harmonic distortion spectrum
GB
RX 22
Stereo
/ Bridged
2 x 180 W / 1 x 500 W
2 x 90 W / 1 x 250 W
2 x 250 W
2 x 125 W
2 – 8 Ohm
5 – 50 000 Hz (-3 dB)
< 0.05 % (1 kHz)
> 60 dB (1 kHz)
> 100 dB
0.4 – 4 V
20 kOhm
40 – 300 Hz, 12 dB per octave
40 – 300 Hz, 12 dB per octave
0...15 dB at 45 Hz
15 Hz, 12 dB per octave
+12 V (9 – 15 V), minus to ground
2 x 15 A
250 x 50 x 261 mm
2.8 kg
8
on 4 Ohm
on 4 Ohm
on 2 Ohm
on 2 Ohm
