Attention: The scraper blade must rest on the pipe end in such a way that during the first
rotation no section of the pipe end remains unscraped. It is helpful to position the scraper
blade in such a way that it rests with its dull section on the pipe edge. This ensures that
the whole pipe end will be scraped successfully.
Carefully lower the scraper blade so that it does not abruptly hit the pipe surface!
4.5
Beginning the peeling procedure
Slow and continuous peeling will deliver better results. If the peeling is carried out too
quickly, the pipe surface may not be sufficiently peeled!
Clamping and fixing the pipe:
Fix or clamp the pipe before you begin peeling it to improve the peeling result and prevent
accidents.
The peeling procedure must be done in a clockwise direction.
Beginning the peeling procedure:
Begin the peeling procedure slowly at first and watch the result.
Continue to peel until you have reached the end of the marked pipe section.
Bringing the peeling arm in the upper position and removing the tool from the pipe:
Bring the scraper arm in the upper position and pull the tool from the pipe.
Note: After removing the tool from the pipe always make sure that you have completely
peeled the desired area!
4.6
Additional notes
In case of an insufficient peeling result the blade has to be replaced.
In consideration of the processing guidelines of the fitting manufacturer and the tolerances spec-
ified therein (max. gap between pipe and fitting) the pipe may be peeled a second time.
The peeler blades are subject to wear.
Use only on cleaned pipe surfaces.
Keep the Pipe End Peeler clean and dry in the suitcase!
The thickness of the peeling must be checked with a suitable measuring instrument on a regular
basis.
ENGLISH
15
