Acksys RailBox Série Guide D'installation Rapide page 34

11ac w2 4T-4R dual band 2.4/5 GHz
Tx output
power
Tolerance ±
2dB
(*)
at the RF QMA connector of the product,
values listed above are given by the radio
card manufacturer at the connector of the
radio card
Rx
sensitivity
input
Tolerance ±
2dB
(*) Add 2 dBm to get the value available at the RF QMA
connector of the product, values listed above are given by
the radio card manufacturer at the connector of the radio
card
Radio card information
Band Modes
2.4 11b/g
5 11a
2.4 11n HT20
2.4 11n/ac HT40
5 11n HT20
5 11n HT40
5 11 ac VHT20
5 11 ac VHT40
5 11 ac VHT80
Subtract 2 dBm to get the value available
Band Modes
2.4 11g
5 11a
2.4 11n HT20
2.4 11n/ac HT40
5 11n/ac VHT20
5 11n/ac VHT40
5 11ac VHT80
per antenna (*)
20 dBm @ 6M
16 dBm @ 54M
19 dBm @ 6M
15 dBm @ 54M
20 dBm @ MCS 0
15 dBm @ MCS 7
20 dBm @ MCS 0
13 dBm @ MCS 9
19 dBm @ MCS 0
14 dBm @ MCS 7
19 dBm @ MCS 0
15 dBm @ MCS 7
19 dBm @ MCS 0
13 dBm @ MCS 8
19 dBm @ MCS 0
12 dBm @ MCS 9
18 dBm @ MCS 0
12 dBm @ MCS 9
1 to 4 antennas (**)
-90 dBm @6M
-73 dBm @54M
-91 dBm @6M
-74 dBm @54M
-89 dBm @MCS 0
-66 dBm @MCS 8
-87 dBm @MCS 0
-68 dBm @MCS 7
-62 dBm @MCS 9
-90 dBm @MCS 0
-71 dBm @MCS 8
-89 dBm @MCS 0
-71 dBm @MCS 7
-65 dBm @MCS 9
-85 dBm @MCS 0
-61 dBm @MCS 9
-16-
From 2 to
4 antennas
Add :
3dBm for 2
antennas
5dBm for 3
antennas
6dBm for 4
antennas
