Acksys RailBox Série Guide D'installation Rapide page 27

M8 3 pole male screw
Connector
Notice: GND signal is common to the Digital Input and Alarm contactor.
Wi-Fi 1
connector female
QMA type
Wi-Fi 2
connector female
QMA type
The antennas configurations for the two WiFi1 and WiFi2 interfaces are:
 Ant.1
 Ant.1 and Ant.2
 Ant.1, Ant. 2 and Ant.3
 Ant.1, Ant. 2, Ant. 3 and Ant.4
To get the full performance of the MIMO 4T/4R technology, you must
connect the 4 antennas (not provided).
If not, the product operates with lower performances.
It is recommended to put a 50 ohms terminator onto the unused
connector.
Antenna configuration must be done as well in the product itself through
the internal webserver.
Digital Input/Alarm connector
Signal name
Digital input (I)
Alarm contactor (O)
WiFi antennas connectors
(4T 4R)
Signal name
Ant.1
Ant.2
Ant.3
Ant.4
Wi-Fi 2 antennas (only for dual radios
Signal name
Ant.1
Ant.2
Ant.3
Ant.4
-9-
Pin
V
in
GND
V
out
GND
WiFi 1 antennas
function
RF Chain 1
RF Chain 2
RF Chain 3
RF Chain 4
models)
Function
RF Chain 1
RF Chain 2
RF Chain 3
RF Chain 4
Wire color
3 Black
2 Brown
1 Blue
2 Brown
