Final Installation - Acksys RailBox Série Guide D'installation Rapide

Wireless interface
The RAILBOX has two WIFI Interfaces whose modes depend of the chosen
model.
Refer to the « REFERENCES » chapter to know the WiFi mode
supported by your WiFi 1 and WiFi 2 interfaces.
The two WiFi interfaces can work alone or simultaneously
Upon delivery, the default factory settings are:
 Access point mode
 SSID "acksys"
 No security
 Automatic radio channel
Setup the Wireless:
a. First, select the band : 2.4 GHz or 5GHz.
b. Enable the WiFi interface (Green color)
c. Click on Edit, to set Wireless essential parameters
Customize your Wireless interface according
 The operating mode: Access point, client (bridge)
 Wi-Fi parameters: 802.11 mode, radio channel, SSID
 Wi-Fi security parameters (WEP, WPA, WPA-PSK, WPA2, WPA2-
PSK, SSID broadcast or not)
 You will find a complete description of all modes in the WaveOS user
guide.
Warning:
Save your settings by clicking "Save & Apply".
Otherwise your settings will be lost if the product has to restart
6. Install the device

Place the device in an appropriate place. The device can be
installed outdoor. Check that all the connectors are protected
thanks to a cable or a cap.
7. Install the antennas

Insure that their position and radiation pattern allow proper
communication with the peer Wi-Fi devices.

Specifically, insure that there are no obstacles between the
device and its peers ("line of sight" concept).

FINAL INSTALLATION

-5-
