The product has 8 LEDs to indicate the status of the product.
LED
Power 1
Power 2
Diag
LAN 1
Green/ Yellow
LAN 2
C-KEY
State
Activity
LEDs definition
Color
Green
Green
Red/ Green
Red/
Green
Green
Blue
This LED is ON when a power supply is
connected to pins PWR1 of the power
connector or a POE source is connected to
LAN2
This LED is ON when a power supply is
connected to pins PWR2 of the power
connector
This led indicates the unit operational state.
OFF:
Power supply is off
Red:
Initialization during
power is applied then goes
Green
Red for more 120s: hardware failure
Green:
Ready to use
Blinking: Firmware in flash is loading
Device is in "emergency mode"
because firmware is corrupted.
Re
WaveManager
On:
Link on LAN established
Flashing: Tx/Rx activity
Yellow:
connected in 1000 BASE T
Green:
10 o100 BASE TX
Off:
Link on LAN broken
Off:
C-KEY in factory state
Red:
The C-KEY is not detected, data
is invalid or corrupt
Green:
The C-KEY data is valid
Blinking:
during reads and writes to the
C-KEY
Off:
the radio is disabled or DFS CAC
Blinking: the product is unassociated
solid "On": the product is associated
Flashing: Radio Tx/Rx activity
-10-
Description
load
firmware
60s
after
with
