Nomenclature et fonctions
Panneau avant
W9
W8
W7
W6
o
Q0 Q1
E0
Q2
q
w
Q8
Q9
W0
Boutons, prises et affichages uniquement disponibles sur l'appareil principal
Q8
Témoin d'alimentation ······························ (16)
Q9
Interrupteur principal (hON jOFF) ·· (16, 59)
W0
Prise de casque audio (PHONES) ·············· (38)
W1
Bornes V. AUX INPUT ································ (15)
W2
Prise SETUP MIC ········································ (20)
W3
Témoin AUDYSSEY DYNAMIC VOLUME
····································································· (43)
W5
W4
W3
Q3 Q4
Q5 Q6
Q7
e r
t y
u
W1
W2
W4
Témoin HD AUDIO ····································· (39)
W5
Témoin MASTER VOLUME
W6
Affichage
W7
Capteur de télécommande ·························· (3)
W8
Touche TUNING PRESET ··························· (36)
W9
Touche SOURCE MODE SELECT ·············· (34)
E0
Touche FRONT SPEAKER SELECT ············ (38)
Boutons fonctionnant de la même manière que les boutons de télécommande
i
Pour les touches qui ne sont pas décrites ici, lire la page indiquée entre parenthèses ( ).
q
Touche d'alimentation
(ON/STANDBY) ·········································· (16)
w
Touches SURROUND MODE ··············· (39, 40)
e
Touche MENU ············································· (17)
r
Touches de curseur (uio p)·················· (17)
t
Touche ENTER ············································ (17)
y
Touche RETURN ········································· (17)
u
Touches QUICK SELECT ···························· (47)
i
Molette de contrôle MASTER VOLUME ··· (34)
o
Molette SOURCE SELECT ·························· (34)
Q0
Touche VIDEO SELECT ······························ (46)
Q1
Touche SLEEP TIMER
·····························
Q2
Touche RESTORER ····································· (44)
Q3
Touche DYNAMIC EQ ································· (43)
Q4
Touche DYNAMIC VOLUME ······················ (43)
Q5
Touche MULTEQ ········································ (43)
Q6
Touche DIMMER ········································· (38)
Q7
Touche STATUS ········································· (45)
n
Les touches qui fonctionnent de la
même manière que les touches du
panneau avant
q
u
o
(46)
Q3
Q5
e
r
t
y
Q6
w
Q0
Q1
Q4
i
Q7
Q2
