1. Explanation of symbols
Symbols
Description
:Double insulation
: See accompanying user manual
2. Intended use and color of the lead Set
A) Test probe has the lead wire which is composed of the Nickel Silver, Copper Braid, and PVC Rubber. One end has a plug
and the other end is 4mm (with cap)or 18mm (without cap) probe tip.
B) Probe length : 1618 mm ± 5.0 mm
C) Wire Color : Black / dimensions : ¢6mm
D) Weight : 126g
3. Specification (Dual rating)
Voltage (a.c/d.c) : 1000 V Current : Max. 10 A
Measurement Category : CAT II (without Caps) / CAT III, CAT IV (with Caps)
4. Identification of operation control
The test probe is generally attached with Digital Multi-meter. It must be in accordance with the relating meter.
(UL 61010-031, CAT II 1000V, CAT III 1000V, CAT IV 600V, 10A)
5.
WARNING
• Before testing, make sure the test probe is connected to the meter. Make sure that the test probe is disconnected from
the test point before the test probe is without connection to the meter.
• If this product is used in manner not specified by the instructions, the protection may be impaired. Replace leads that
have the inner contrasting color of the wire exposed.
• Do NOT use test probe in CAT III or CAT IV environments without the cap is assembled with test probe and correct category
rating visible on the cap. When the cap is not assembled with test probe, the probe tip is 18mm and rated to CAT II 1000V.
• When used with meter or other accessories, the lowest category rating of the combination applies.
6. Instructions for cleaning
Wipe the dirty parts with gauze or soft cloth soaked with dilute detergent. After cleaning, leave the test probe until it
dries completely.
WARNING - Before cleaning the test probe, make sure the test probe is disconnected from Meter and test point.
Remote Probe Set
19
