MiniLift200
Extremely comfortable, active sit-to-stand with natural
movement pattern
MiniLift200 has been developed to, as gently and comfortably as
possible, assist the user when rising from a sitting to a standing
position. The handles and the side supports offer multiple hand place-
ment options for the user. The stable anti-slip foot plate is very low and
the lower leg supports, as well as the lifting arm, can be adjusted to fit
every user optimally. When MiniLift200 is used in combination with the
appropriate lifting accessories, the user is supported under the feet,
for the front of the lower legs and behind the back, which provides for
a safe and secure, yet active sit-to-stand procedure. The construction
safely moves the user forwards and upwards in a natural movement
pattern and, at the same time, the leg muscles and balance are
exercised. MiniLift200 is manufactured in steel for stability and strength
and is suitable also for tall and heavy users weighing up to
200 kg/440 lbs.
Active sit-to-stand with natural
movement pattern.
ACCESSORIES
Art. No.
45500003
45500004
45500006
45500007
45500008
45500003-009
45500009
45550004
45550006
45550007
45550008
45550009
45590004
45550004-009
45590006
45590007
45590008
45600004
45600006
45600007
45600008
45600004-008
45690004
45690006
45690007
45690008
70200033
70200012
70200089
45690004-008 70200029
Other models and variants of MiniLift mobile sit-to-stand lifts
MiniLift is available in several models and variants with different lifting capacity, with electrical or manual base-width adjustment and with standard height
or low legs for use with lower beds.
Art. No.
60300010
60300011
60300012
60300013
400641434
SystemRoMedic is a complete solution for easy transfers. The concept
TM
encompasses four product areas that meet most needs in different transfer situations.
Transfer, between two locations. Positioning, within the same location.
Support, for mobility. Lifting, both manual and mechanical.
Product name Description
ThoraxSling Polyester, X-Small
ThoraxSling Polyester, Small
ThoraxSling Polyester, Medium
ThoraxSling Polyester, Large
ThoraxSling Polyester, X-Large
ThoraxSling Polyester, XX-Large
ThoraxSling Wipeable, Small
ThoraxSling Wipeable, Medium
ThoraxSling Wipeable, Large
ThoraxSling Wipeable, X-Large
ThoraxSling Wipeable, XX-Large
ThoraxSling Disposable, non-woven, Small, 5 pcs
ThoraxSling Disposable, non-woven, Medium, 5 pcs
ThoraxSling Disposable, non-woven, Large, 5 pcs
ThoraxSling Disposable, non-woven, X-Large, 5 pcs
ThoraxSling With seat support, polyester, Small
ThoraxSling With seat support, polyester, Medium
ThoraxSling With seat support, polyester, Large
ThoraxSling With seat support, polyester, X-Large
ThoraxSling With seat support, disposable, non-woven, Small, 5 pcs
ThoraxSling With seat support, disposable, non-woven, Medium, 5 pcs
ThoraxSling With seat support, disposable, non-woven, Large, 5 pcs
ThoraxSling With seat support, disposable, non-woven, X-Large, 5 pcs
CalfStrap For MiniLift200 as from serial number 200001277
SlingBarWrap MiniLift Soft, wipeable protection for the bar of MiniLift200
Hand control HB33-6 6 buttons, with service, battery status and overload indicators
External charger Linak External charger for all models and variants of MiniLift
Product name Description
MiniLift160EM Mobile sit-to-stand lift with manual base widening, SWL 160 kg/350 lbs
MiniLift160EM Mobile sit-to-stand lift with manual base widening, low legs, SWL 160 kg/350 lbs
MiniLift160EE Mobile sit-to-stand lift with electrical base widening, SWL 160 kg/350 lbs
MiniLift160EE Mobile sit-to-stand lift with electrical base widening, low legs, SWL 160 kg/350 lbs
MiniLift125 Mobile sit-to-stand lift with electrical base widening, SWL 125 kg/275 lbs
PRODUCT SPECIFIKATION
MiniLift200 Mobile sit-to-stand lift with electrical base widening Art. No. 401100334
TECHNICAL INFORMATION
Safe working load (SWL)
User length, min-max
Material
Height
Length
Width of base, outer measurement
Width of base, inner measurement
Weight
Base widening
Height of footplate, for user
Castor size, diameter
Lifting speed, without load
Emergency lowering
MiniLift200 meets the requirements of the Medical Devices Directive for Class 1 products
93/42EEC.
Ergonomic
and easy-to-
use hand
control with
4 buttons.
200 kg / 440 lbs
1400-2000 mm / 55.1-78.7"
Powder-coated steel
1000 mm / 39.4"
980 mm / 38.6"
590-1030 mm / 23.2-40.6"
450-875 mm / 17.7-34.4"
49 kg / 108 lbs
Electrical
95 mm / 3.7"
100 mm / 3.9"
35 mm / 1.4" per sec
Manual and electrical
New control box with
diagnostics, e.g. lift
counter and overload
indicator.
Electrical emergency
stop button readily
available on the control
box.
ThoraxSling
SystemRoMedic ™
ThoraxSling is a specially adapted and
very comfortable sit-to-stand vest that
is used in combination with Handicare's
SystemRoMedic™ MiniLift sit-to-stand
lifts. It is easy for the caregiver to apply,
while giving the user an added sense of
security during rising and standing
training. ThoraxSling also facilitates
toileting. ThoraxSling is available in two
models; one which provides support
behind the back (ThoraxSling) and one
that also gives support under the seat
(ThoraxSling, with seat support), and in
several materials and sizes.
