English
Storage Recommendations
1. The best storage place is one that is cool and dry, away
from direct sunlight and excess heat or cold.
2. For long storage, it is recommended to store a fully
charged battery pack in a cool dry place out of the
charger for optimal results.
nOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be
recharged before use.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
COMPONENTS (FIG. A)

WARNING: Never modify the power tool or any part
of it. Damage or personal injury could result.
Refer to Figure A at the beginning of this manual for a
complete list of components.
Intended Use
This impact wrench is designed for professional impact
fastening and drilling applications. The impact function
makes this tool particularly useful for driving fasteners in
wood, metal and concrete.
DO nOT use under wet conditions or in presence of
flammable liquids or gases.
This impact wrench is a professional power tool. DO nOT
let children come into contact with the tool. Supervision is
required when inexperienced operators use this tool.
Variable Speed Trigger Switch (Fig. A)
To turn the tool on, squeeze the trigger switch
the tool off, release the trigger switch. Your tool is equipped
with a brake. The anvil will stop when the trigger switch
is fully released. The variable speed switch enables you to
select the best speed for a particular application. The more
you squeeze the trigger, the faster the tool will operate. For
maximum tool life, use variable speed only for starting holes
or fasteners.
nOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
be avoided.
Forward/Reverse Control Button (Fig. A)
A forward/reverse control button
direction of the tool and also serves as a lock‑off button.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side
of the tool.
To select reverse, release the trigger switch and depress the
forward/reverse control button on the left side of the tool.
The center position of the control button locks the tool in
the off position. When changing the position of the control
button, be sure the trigger is released.
nOTE: The first time the tool is run after changing the
direction of rotation, you may hear a click on start up. This is
normal and does not indicate a problem.
8
1 . To turn
determines the
2
Worklight (Fig. A)
There is a worklight 7 located on the foot of the tool. The
worklight is activated when the trigger switch is depressed,
and will automatically turn off 20 seconds after the trigger
switch is released. If the trigger switch remains depressed,
the worklight will remain on. The light's timeout can be
adjusted or the light disabled in ToolConnect™.
nOTE: The worklight is for lighting the immediate work
surface and is not intended to be used as a flashlight.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can cause injury.
Tool Connect™ Mode Selector (Fig. D)

WARNING: To reduce the risk of injury, remove
accessories from the tool chuck before using the
mode selector.
The DCF896 and DCF896H are equipped with a mode
selector that allows Modes 1, 2, and 3 to be customized
using the Tool Connect™ app (refer to Table 1). Once
configured, pressing the mode selector button
foot of the tool will cycle through the modes
Mode settings are not customizable and the Home Mode is
active when the home indicator
If you are unsure of the current configuration, press the
mode selector button
8
(home indicator is lit).
12
Fig. D
8 12
Precision Wrench™ (Fig. D)
In addition to normal impacting modes, this tool features
the Precision Wrench™ mode which grants the user greater
control in both fastening and loosening applications.
When set in forward, the tool will fasten at 2000 RPM until
impact begins. The tool will pause for a duration set by
the user in Tool Connect™ before continuing to impact
at a rate of 3100 IPM, providing the user with greater
control and reducing the chance of overtightening or
damaging material.
When set in reverse, the tool will impact at a normal speed
and rate of 3100 IPM. Upon sensing that the fastener has
broken free, the tool will cease to impact and will reduce
speed to help prevent "run‑off" of loose hardware. Speed
reduction can be set by the user in ToolConnect™.
8
13 . The Home
12 is lit.
to set the tool to the Home Mode
13
on the
