LEGRAND Wattstopper FSP-311B Mode D'emploi page 5

False Triggering may occur if the sensor is exposed to high ambient temperature conditions and the unit is set to maximum sensitivity
for PIR detection.
• If this occurs, reduce the PIR sensitivity setting from maximum to a medium point and re-check unit operation.
• If experiencing false triggering during fade down/Off, try increasing the fade time.
Lights do not turn ON:
Check for blinking blue LED. If the LED blinks twice, the sensor has reached its Hold Off setpoint, if the LED blinks 3 times, the sensor
has reached it's Photocell Light Level setpoint.
Lights suddenly turn off and will not come back on:
Check for blinking blue LED. If the LED blinks twice, the sensor has reached its Hold Off setpoint, if the LED blinks 3 times, the sensor
has reached its Photocell Light Level setpoint.
I forgot my password:
Hold the reset button under the sensor lens for 15 seconds. This will reset the device to default values and allow you to assign a new password.
I can't discover the sensor on the app:
If you do not connect with the sensor for 7 days after being powered on, the radio stops broadcasting. Power cycle the sensor in order to
enable the radio.
Catalog #
FSP-311B Continuous Dimming, PIR Fixture Integrated Sensor in IP66 Enclosure
FSP-311B-S High/Low/Off, PIR Fixture Integrated Sensor in IP66 Enclosure, with Straight Nipple Mount
FSP-311B-D High/Low/Off, PIR Fixture Integrated Sensor in IP66 Enclosure, with Drop Nipple Mount
FSP-L2 360° lens, up to 44' diameter at 8' height
FSP-L2-S 360° lens, up to 44' diameter at 8' height, with shroud
FSP-L3 360° lens, up to 40' diameter at 20' height
FSP-L3-S 360° lens, up to 40' diameter at 20' height, with shroud
FSP-L7 360° lens, up to 100' diameter at 40' height
FSP-L7-S 360° lens, up to 100' diameter at 40' height, with shroud
FSP-C1 Small collar, for use with FSP-L2 and FSP-L3 lenses
FSP-C2 Large collar, for use with FSP-L7 lens
Sensor colors indicated by one of the following suffixes at the end of the catalog #:
-W = White; -B = Black; -BR = Bronze/Brown; -G = Gray/Silver
ORDERING INFORMATION
Description
5
