Error codes:
Err08:
Pythagorean measurement error
Replace the battery
Err10:
Err11:
Data transfer error
Err14:
Calculation error
Err15:
Outside the measuring range
Received signal too weak
Err16:
Err26:
Value outside display range
Information on maintenance and care
Clean all components with a damp cloth and do not use cleaning agents,
scouring agents and solvents. Remove the battery(ies) before storing for
longer periods. Store the device in a clean and dry place.
Calibration
The measuring device should be calibrated and tested on a regular
basis to ensure it is accurate and working properly. We recommend
the measuring device is calibrated every 1 - 2 years. If necessary, contact
your distributor or the UMAREX-LASERLINER service department.
Technical Data (Subject to technical changes without notice. 24W06)
Precision (typical)*
Measurement range
(inside)**
Laser class
Laser wave length
Automatic switch-off
Power supply
Operating conditions
Storage conditions
Dimensions (W x H x D)
Weight
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase
by ± 0.2 mm/m for weakly reflective target surfaces.
** at max. 5000 lux
14
EN
± 2 mm
0,3 m - 40 m
2 / < 1 mW (EN 60825-1:2014/
A11:2021 / EN 50689-1:2021)
515 nm
30 sec laser / 3 min device
2 x 1,5V LR03 (AAA)
-10°C ... 40°C, max. humidity 20 ...
85% rH, no condensation, max. working
altitude 2000 m above sea level
-20°C ... 70°C,
max. humidity 80% rH
40 x 110 x 24 mm
90 g (incl. batteries)
