4. Short press [-] or [+] to adjust the preset speed.
50%
55%
60%
65%
70%
75%
80%
85%
Default factory setting of the fan speed is selected depending on the device's length in order to guarantee the sound levels.
5. After 30 seconds, the new settings are automatically saved and the device returns to the selected mode.
4.3. SWITCH ON/OFF WINDOW CONTACT
1. remember the original setting of the rotary switch
2. turn the rotary switch to setting '0'
3. the 3 LEDs (red, green and blue) on the JDPC are blinking
4. hold the '-' button down until the blue or the red LED lights up
5. the setting of the window contact changed
–  blue LED: window contact inactive
–  red LED: window contact active
6. repeat these steps until the desired result is obtained.
7. turn the rotary switch back to its original setting
4.4. FACTORY RESET
1. Disable power charge.
2. Press and hold down both the [-] and [+] button on the circuit board and switch on the
power again. The blue LED will light up, followed by the green LED 2 seconds later and
the red LED 4 seconds later. Release the buttons as soon as all 3 LEDs are flashing.
3. The controller will return to the Factory Default settings, all LEDs will flash for 8 seconds.
STRADA HYBRID TPT/B | MANUEL | 2024.07.01 | V.1.03
MODE
MODE
MODE
MODE
MODE
MODE
MODE
MODE
90%
MODE
95%
MODE
100%
MODE
105%
MODE
110%
MODE
115%
MODE
120%
MODE
EN
45
