2.2. OPERATION
Upon recognising the correct water temperature, the fan will modulate depending on the difference between the
measured room temperature and the desired room temperature.
Tw > 28C
The user chooses the desired room temperature on the control panel in heating or cooling. The thermoelec-
tric valve will stay open until the room temperature is reached.
MODE
3. CONTROL
Tw < 24ºC
MODE
Tw < 24ºC
Tset < Tk
MODE
The user chooses the temperature via the [-] and [+] button.
Snelheid 1
The unit starts as soon as the control panel
is in cooling mode, the requested room
MODE
temperature has not been reached and the
10 sec
water temperature is < 24°C.
MODE
10 sec
26 ̊ C
24 ̊ C
23 ̊ C
22 ̊ C
21.5 ̊ C
21 ̊ C
20.5 ̊ C
20 ̊ C
19 ̊ C
18 ̊ C
16 ̊ C
The speed is controlled automatically and the max speed corresponds to 30 dB(A).
42
Tw < 24C
MODE
MODE
Tw > 28ºC
Tset > Tk
MODE
Snelheid 2
MODE
MODE
MODE
Tw > 28ºC
MODE
O
MODE
Snelheid 3
The unit starts as soon as the control panel
is in heating mode, the desired room tempe-
MODE
rature has not been reached and the water
temperature is > 28 ̊ C .
MODE
