8. Connection of the stove to the chimney

The stove can be connected directly to the chimney (outlet at the back). The diameter of the outlet duct
must correspond with the 150mm diameter of the stove's outlet connector.
If the draught of the chimney is too strong, a draught regulator must be built in.
You must also take the following into account with regard to the diameter of the outlet duct:
• The diameter of the outlet duct may not be reduced. In addition, the outlet duct must fit perfectly
onto the chimney.
• The stove duct may not be smaller than the diameter of the chimney, since this will hamper the
upward pressure of the fumes. In order to prevent this, you should provide a double wall lining.
• The chimney connections of different fireplaces may not be situated opposite one another or at the
same height, since this could also hamper the removal of combustion gases. Two connections of
fume outlet ducts must be situated at least 30 cm away from one another.
• The chimney may not contain too many connections – this hampers the upward pressure. Consult
your chimney-sweep!
• The chimney may not conduct any false air. Check for closed chimney sliders and cleaning hatches
in the cellar or on the roof!
• The outlet duct must be securely attached to the connector pipe.

9. Before first use

When the heating appliance is used for the very first time, it must first dry out completely. For this
purpose, heat it for one hour with a small quantity of fuel. Set the air inlet to " I ".
During this phase, a slight odour may be given off due to the curing of the primer used.
Keep an eye on the appliance during this phase and immediately remove any water formed by
condensation, before it can burn into the enamel or the lacquer.

10. The controls

•
Adjustment of the feet
In order to make levelling of the appliance possible, the feet on both sides have small setscrews that
can be adjusted separately.
52
