9
Technical specifications
9.1
General technical specifications
Technical specifications
Temperature application range:
Humidity application range:
Protection category:
Protection class:
Overvoltage category:
Degree of contamination:
max. operating height:
min. operating time:
EU conformity:
Electrical connection data
Differential current measurement range AC/DC
Connection cable type
No. of wires
Input cable length
Output cable length
CEE connector input (depending on RCM version)
CEE coupling output (depending on RCM version)
10
Service
For technical questions, please contact:
Tel.: +49(0)2772 505-9052
E-mail: info@rittal.de
Homepage: www.rittal.com
For complaints and service requests, please contact:
Tel.: +49(0)2772 505-1855
E-mail: service@rittal.de
Rittal RCM Inline Meter
Technical specifications, Service
Temperature Operation: +5 °C...+50 °C (at 100% load)
+5 °C...+60 °C (at 80% load)
Temperature Storage: -20 °C...+70 °C
10%...95% relative humidity, non-condensing
IP 20 to IEC 60 529
1
II
2
3,000 meters above sea level
100,000 h
Low-Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
IEC/EN 62368
DK01:
16 A, single-phase (230 V), 50/60 Hz
DK02:
32 A, single-phase (230 V), 50/60 Hz
DK03:
16 A, 3-phase (400 V), 50/60 Hz
DK04:
32 A, 3-phase (400 V), 50/60 Hz
+/- 100 mA
H05-VV
3/5 (single-phase/3-phase RCM)
2 m
1.2 m
16 A / 32 A, 6 h, L-N-PE, 230 V AC, 50 Hz...60 Hz
16 A / 32 A, 6 h, 3L-N-PE, 400 V AC, 50 Hz...60 Hz
16 A / 32 A, 6 h, L-N-PE, 230 V AC, 50 Hz...60 Hz
16 A / 32 A, 6 h, 3L-N-PE, 400 V AC, 50 Hz...60 Hz
EN
33
