• Technical characteristics

Case
Dimentions (w x h x d):
Connection:
IP index:
Weight:
Display
Type:
Auxiliary supply
Voltage:
Frequency:
Consumption:
Inputs
Passive configuration:
Active configuration:
Configuration GME S0:
Pulse duration:
Pulse frequency:
Length of the line:
Operating Conditions
Operating temperature:
Storage temperature:
Relative humidity:
CE Marking
The 4 120 65 product complies with:
• the requirements of the European directive on electromagnetic compatibility (EMC) n° 2004/108/EC
• low voltage directive no. 73/23/CEE dated 19 February 1973, modified by directive no. 93/68/CEE dated 22 July
1993, modified by directive n° 2006/95/CE.
Electromagnetic compatibility
Emission test according to EN 61326-1
Immunity test according to EN 61326-1
Insulation (IEC/EN 61010-1)
Installation category:
Degree of pollution:
Rated impulse withstand voltage:
EMDX multi-utility pulse concentrator
3
89,5 x 70 x 65,6 mm
Flexible cable- 2,5 mm
2
Front IP50, terminals IP20
280 g
LCD
230 Va.c. (-15 %) ÷ (+10%)
50/60 Hz
≤ 5VA
12 potential free SPST-NO inputs
Internal digital input polarisation power supply: 5 Vd.c.
6 potential free SPST-NO inputs
6 active inputs max. 27 Vd.c. (Type 2 IEC/EN 61131-2)
6 potential free SPST-NO inputs
1 input S0 complies with IEC/EN 62053-31 (Class B)
≥ 20 ms
max. 25 Hz
1000 m, section min. 1.5mm²
(-10 °C) ÷ (55 °C) [14 °F ÷ 131 °F]
(-25 °C) ÷ (70 °C) [-13 °F ÷ 158 °F]
≤ 75%
III
2
4 kV
