PH10M-iQ PLUS installation and user's guide
www.renishaw.com
No head movement in automatic mode
Possible cause
Head controller in manual mode
Power loss
Cable / connection fault
Communications failure
Incorrect command set selected
PICS STOP is asserted by other system component
No head movement in manual mode
Possible cause
Head controller in automatic mode.
Power loss
Cable / connection fault
Issued 12 2021
Solution
Change to automatic mode.
Check mains cable connections and integrity.
Check power block is supplying 24 V.
Check CMM emergency stop condition - power may have been
removed by CMM.
Check connection and integrity of cabling between head and
controller.
Check RS232 baud rate.
Check correct command set is selected.
Clear the fault asserting PICS STOP.
Solution
Change to manual mode.
Check mains cable connections and integrity.
Check power block is supplying 24 V.
Check CMM emergency stop condition - power may have been
removed by CMM.
Check connection and integrity of cabling between head and
controller.
