PH10M-iQ PLUS installation and user's guide
www.renishaw.com
Powering PHC10-3 PLUS
The PHC10-3 PLUS head controller is to be used with the provided PSU. This is a 24 Vdc 40 W supply and is connected to the PHC10-3 PLUS
via Ø5.5 mm dc jack plug.
NOTE: PHC10-3 PLUS does not does require a protective earth, however an equipotential bonding point is provided on the rear
panel for connection to the rest of the installation.
NOTE: For system interconnection diagrams refer to the PHC10-3 PLUS installation guide (Renishaw part number H-1000-7592).
Issued 12 2021
25
