Specification
Sample types
Measurement range
Repeatability
Reproducibility
Accuracy
Limit of detection (LOD)
Response time (90%)
Display resolution
Calibration
Calibration sample
Ambient temperature
Humidity
Operating altitude
Environmental conditions
Power supply
Wall and pipe mount
instrument (H x D x W)
Panel mount instrument
(housing) (H x D x W)
M1100 12 mm (PG 13.5)
sensor (L x W)
K1100 and M1100 28 mm
sensor (L x W)
Calibration device
Section 2 Online user manual
This Basic User Manual contains less information than the User Manual, which is available on the
manufacturer's website.
Section 3 General information
In no event will the manufacturer be liable for damages resulting from any improper use of product or
failure to comply with the instructions in the manual. The manufacturer reserves the right to make
4 English
Details
K1100 sensor: Water only
M1100 sensor (low range): Water and beer
M1100 sensor (high range): Water, beer, wine, wort and carbonated drinks
Low range sensors: 0 to 2,000 ppb (dissolved. Indicative values until 5000 ppb)
High range sensors: 0 to 40 ppm (dissolved)
Low range sensors: ± 0.4 ppb or 1%, whichever is the greater
High range sensors: ± 0.015 ppm or ± 2% whichever is the greater
Low range sensors: ± 0.8 ppb or 2%, whichever is the greater
High range sensors: ± 0.02 ppm or ± 3% whichever is the greater
Low range sensors: ± 0.8 ppb or 2%, whichever is the greater
High range sensors: ± 0.02 ppm or ± 3% whichever is the greater
Low range sensors: 0.6 ppb
High range sensors: 0.015 ppm
Low range sensors: < 10 seconds in gas phase; < 30 seconds in liquid phase
High range sensors: < 10 seconds in gas phase; < 50 seconds in liquid phase
0.1 ppb
Low range sensors: Single point calibration (zero)
High range sensors: Two at cap replacement (zero and air), one during use (air)
Low range sensors: Standard 99.999% N
gas
High range sensors: Standard 99.999% N
gas, air
-5 to 50°C (23 to 122°F)
0 to 95% non-condensing relative humidity
2000 m (6561 ft) maximum
Indoor use
Universal 85-264 VAC @ 50/60 Hz, 25 VA
10-36 VDC, 25 W
236.5 x 160 x 250 mm; Weight 4.25 kg
9.31 x 6.30 x 9.84 in.; Weight 8.82 lbs
156 (123) x 250 x 220 (214) mm; Weight 3.35 kg
6.14 (4.84) x 9.84 x 8.86 (8.43) in.; Weight 6.62 lbs
246 x 47 mm; Weight 0.6 kg
9.69 x 1.85 in.; Weight 1.32 lbs
143.50 x 49 mm; Weight 0.74 kg
5.65 x 1.93 in.; Weight 1.63 lbs
Weight 0.7 kg
(quality 50) or equivalent oxygen free
2
(quality 30) or equivalent oxygen free
2
