Cameo ROOT PAR TW Manuel D'utilisation page 13

Starting from the main display, press MODE to go to the main menu. Using UP and DOWN, now
select the Stand Alone menu option and press ENTER to confirm. Use the UP and DOWN buttons
again to select Direct, press ENTER to confirm, and then use UP and DOWN to select the menu
option you'd like to adjust. Confirm with ENTER. You can set the value as desired from 000 to 255
using UP and DOWN. Then press ENTER to confirm all entries.
STAND-ALONE MODE CCT (CORRELATED COLOR TEMPERATURE)
The color temperature can be set in 100 K steps from 3100 K to 6500 K in the stand-alone CCT
mode. The brightness and strobe effect can also be configured.
Starting from the main display, press MODE to go to the main menu. Using UP and DOWN, now
select the Stand Alone menu option and press ENTER to confirm. Use the UP and DOWN buttons
again to select CCT, press ENTER to confirm, and then use UP and DOWN to select the menu
option you'd like to adjust. Confirm with ENTER. Using UP and DOWN, select the desired value and
then press ENTER to confirm all entries.
STAND-ALONE MODE LOOP/SOUND
The stand-alone mode Loop makes it possible to individually design and reproduce a lighting
sequence. Brightness, step time, fade time, music control with microphone sensitivity, and delay
(signal delay) can be set separately.
Starting from the main display, press MODE to go to the main menu. Using UP and DOWN, now
select the Stand Alone menu option and press ENTER to confirm. Use UP and DOWN again to
select the desired Loop stand-alone mode and press ENTER to confirm your selection.
Direct Mode
Dimmer Brightness
Strobe Strobe effect
Cold White Cold white
Warm White Warm white
CCT Mode
Dimmer Brightness
Strobe Strobe effect
CCT Correlated color
temperature
0–255
0–5 = deactivated
6–255 = approx. 1 Hz–20 Hz
0–255
0–255
0–255
0–5 = deactivated
6–255 = approx. 1 Hz–20 Hz
3100 K–6500 K
13
