SETTING DMX MODE
Starting from the main display, press MODE to go to the main menu. Using the UP and DOWN
keys, now select the DMX Mode menu option and press ENTER to confirm your selection. Use
UP and DOWN again to select the desired DMX mode and press ENTER to confirm your selection
(DMX modes with DMX delay channel are marked with "D"). You can find tables on channel assig-
nment in the different DMX modes in these instructions under DMX CONTROL.
DMX DELAY
The DMX Delay function allows a chaser light effect to be easily created with any number of
spotlights of the same model and software version, which could otherwise only be achieved with
a suitable DMX controller and complex programming. All spotlights integrated into the setup are
set to the same DMX mode and controlled with the same DMX start address.
Manually set the DMX delay for DMX operating modes without DMX delay channel (1CH,
2CH, 3CH1, 3CH2, 7CH):
MENU to go to the main menu. Using the and keys, now select the DMX Delay menu option
and press enter to confirm your selection. Use and again to select the desired submenu
item, press ENTER to confirm, set the corresponding value as desired. Press ENTER to confirm all
entries.
Assign the spotlight to one of 95 groups (maximum number of groups depending on the activated
DMX mode). Several spotlights can also be assigned to one group. The group number is also the
factor by which the set delay time is multiplied.
The delay time (delay time of the DMX signal) can be set manually on each spotlight separately
with different values (0.0s to 2.0s in 0.1s steps).
