PARTS LIST
KEY
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
103911
All manuals and user guides at all-guides.com
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 15 of this manual.
PART
NO.
DESCRIPTION
099568-01
Inner Shell (Combustion Chamber)
M11084-26
Hex Tap Screw, #10-16 x 3/8"
099599-02AC
Outer Shell (RCLP50B)
M51104-01
Handle
099230-01
Hex Tap Shoulder Screw
M11084-29
Hex Tap Screw, #10-16 x 3/4"
M11084-27
Hex Tap Screw, #10-16 x 1/2"
099237-01
Thermocouple Clip
099727-03
Burner Assembly
100588-01
Electrode Ignitor
M11084-38
Hex Tap Screw, #8-18 x 3/8"
099537-03
Fan
100589-01
Motor Assembly (Includes Rubber Washer and Fan Nut)
099540-01
Fan Guard
097384-02
Captive Washer Nut
097968-05
Hex Screw, #4-40 x 1/2"
NPC-00C
Hex Nut, #4-40
101732-01
Thermal Switch Kit
097776-01
Universal Bushing
099542-01
Wire Clip
099538-01
Thermocouple
100591-01
Automatic Control Valve w/Orifice
102445-01
Piezo Ignitor
078978-03
Sleeve Cap
103892-02
Base
100397-01
Lock Washer, #4
099202-02
Steel Rivet, 1/8"
100594-01AA
Painted Cover
100184-02
Relay
098219-25
Power Supply Cord Assembly
099125-01
Terminal Board
099157-01
Rivet
097968-01
Hex Screw, 4-40 x 1/4"
098835-01
Hex Nut, 1/2"-28
M50104-01
Shorty Bushing
M11143-1
Strain Relief Bushing
100596-01AC
Wire Guard (RCLP50B)
M11084-37
Hex Screw, 8-18 x 1/4"
079010-14
Wire Assembly, Red
079010-21
Wire Assembly, White
099460-01
Hex Cap, 1/8-27 NPTF
PARTS AVAILABLE - NOT SHOWN
097941-21
Tradename Decal (RCLP50B)
101491-06
General Information Decal
101490-02
Operation Decal
100579-02
Electrical Decal
LPA1020
10' (3 m) Hose
LPA2140
Regulator
LPA3055
Hose and Regulator Assembly
QTY.
1
7
1
1
4
2
3
1
1
1
8
1
1
1
3
2
4
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
2
1
1
1
1
1
2
1
1
2
1
1
1
17
