SPECIFICATIONS
WIRING
DIAGRAMS
14
All manuals and user guides at all-guides.com
Output Rating (BTU/Hr)
Fuel
Fuel Consumption
Gallons (liters)/Hour
Pounds (kg)/Hour
Supply Pressure To Regulator
Minimum (for purposes
of input adjustment)
Maximum
Regulator Outlet Pressure
Manifold Pressure
Hot Air Output
(CFM Approx)
Motor
Electric Input
Amperage
Ignition
Weight
Heater
Shipping
Size - L x W x H
Heater
Temperature Range for Heater Operation
* When running heater in temperatures above 85° F (29.5° C), high internal
temperatures may cause thermal limit device to shut down heater.
Electrode
Piezo
Ignitor
Thermal
Switch
Thermo-
Blue
couple
8
7
Red
6
5
Relay
Red
4
3
2
1
Gas
Valve
Blue
2 1
Blue
Black
Black
Line
Figure 15 - Electrical Ladder Diagram
49,500
Propane Vapor Only
0.5 (1.9)
2.3 (1.04)
10 psi (69 kPa)
Tank Pressure or 200 psi (1380 kPa)
18" WC (46 cm)
16" WC (41 cm)
275 (7.8 m
3300 RPM
120 volt/60 hertz
2
Manual, Piezo
15.5 lb. (7 kg)
17 lb. (7.7 kg)
18.5 x 7.7 x 12.8 inches
(47 x 19.6 x 32.5 cm)
-20° F to 85° F (-6.7° C to 29.5° C)*
Green
Motor
Terminal
Black
Blue
T
White
White
CONNECTION DIAGRAM
(To Thermocouple)
Red
Figure 14 - Wiring Diagram
Blue
Thermal
R l
(To Thermocouple)
Red
Red
Blue
Thermal
Relay
Switch
White
Motor
Green
Ground
3
)
Board
Black
White
Green
Red
White
White
White
Neutral
