OBSIDIAN CONTROL SYSTEMS NETRON RP2 Guide D'installation page 25

R E M O T E D E V I C E M A N A G E M E N T ( R D M )
DMX StartUp(0x0142)
Controller: (GET)
(Port ID)
0x01 - 0xFF
(CC)
GET_COMMAND_RESPONSE
Response:
(Response Type)
ACK
(CC)
GET_COMMAND_RESPONSE
Controller: (SET)
(Port ID)
0x01 - 0xFF
(CC)
SET_COMMAND_RESPONSE
Scene:
1==Off
2==OUTPUT_1_ON
3==OUTPUT_2_ON
4==OUTPUT_1+2_ON
(Message Count)
0x00
(PID)
0x0142
(PD)
Not Present
(Message Count)
0x00-0xFF
(PID)
0x0142
(PD)
Scene # (16-bit)
Loss of Signal Delay (16-bit)
Hold Time (16-bit)
Level (8-bit)
(Message Count)
0x00
(PID)
0x0142
(PD)
Scene # (16-bit)
Loss of Signal Delay (16-bit)
Hold Time (16-bit)
Level (8-bit)
25
(Sub-Device)
0x0000 (Rood)
(PDL)
0x00
(Sub-Device)
0x0000
(PDL)
0x07
(Sub-Device)
0x0000 (Root)
(PDL)
0x07
