OBSIDIAN CONTROL SYSTEMS NETRON RP2 Guide D'installation page 11

C O N N E C T I O N S : F R O N T & B A C K PA N E L S
F R O N T C O N N E C T I O N S
M10
DMX Port Status
Indicator LED
5Pin DMX port, DMX In
5Pin DMX port, DMX Thru
LED Color
DMX PORTS RED
DMX PORTS GREEN
DMX PORTS BLUE
DMX PORTS WHITE
R E A R C O N N E C T I O N S
Fuse: T16A/250V
Power: 100-240VAC
47-63Hz, 16A max.
:
DMX PORTS STATUS INDICATOR LEDs
Solid
DMX In
DMX Out Stable
POWER PORTS STATUS INDICATOR LEDs
LED Color
RED
GREEN
OFF
Status Indicators
Blink
DMX Lost
DMX Lost
Status
Error
Relay is ON
Relay is OFF
100-240VAC
16A max. combined
11
1.3" OLED Display
M12
Turn to scroll,
push-to-select
Menu return button
Routing
Flash on RDM packets
Power Out 1
Power Out 2
