Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Introduction
This an additional remote control panel which is designed
exclusively for use with the AW-RP605 Multi-Function
Controller.
Accessories
Intercom jack (M6 jack) . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Use the dedicated AC adapter (AW-PS505) for the power supply.
Refer to the Operating Instructions of the AW-RP605 Multi-Function Controller for further details on how to
operate this remote control panel.
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Up to two of these units can be added to the AW-RP605
Multi-Function Controller, thereby making it possible to
connect 3 remote control panels in all.
Rack mounting adapters (5U) . . . . . . . . . . . . . . . . . . . . .2
Mounting screws (M4a8 mm) . . . . . . . . . . . . . . . . . . . . .4
4 (E)
