TOOLS NEEDED: ⁵⁄₁₆" hex-head socket wrench, No. 2 Phillips screwdriver, flat-blade screwdriver, ⁵⁄₁₆" open-end wrench, flat 2" putty
knife.
IMPORTANT: Before you begin, turn the refrigerator control OFF. Unplug refrigerator or disconnect power. Remove food from doors.
Door Removal &
Replacement
Top Hinge
A
B
C
A. 5 / " Hex-Head Hinge Screws
16
B. Top Hinge
C. Spacer
Center Hinge
A
B
C
D
E
F
A. Door Stop
B. Door Stop Screw
C. Spacer
D. Center Hinge
5
E. / " Hex-Head Hinge Screws
16
F. Spacer
Bottom Hinge
A
B
C
D
E
A. Door Stop
B. Spacer
C. Door Stop Screw
D. Bottom Hinge
E. 5 / " Hex-Head Hinge Screws
16
6
Refrigerator Doors
Door Swing Reversal (optional)
A
A. Cabinet Hinge Hole Plugs
2
A
B
A
A. Door Hinge Hole Plug
A
A. Flat-Head Handle Screws
B. Freezer Handle
A. Door Handle Sealing Screws
Front View Side View
A. Door Stop Screw
A B
B. Door Stop
1-2
A
5
A. / " Hex-Head Hinge
16
Screws and Washers
3
4
A
A. Door Handle
Seal Screw Front
5
A. Flat-Head Handle Screw
B. Refrigerator Handle
C. Handle Screw
D. Screw Cover
1-1
7
6
A
B
C
D
