ASSEMBLY INSTRUCTIONS
Option 2
Vanity Feet Installation
4. Insert vanity feet (D) into vanity base (B). Attach vanity foot (D) to the
vanity base (B) by inserting the bolts (CC) through lock washers (DD)
and small flat washers (EE). Tighten with hex wrench (FF).
Hardware Used
CC
5/16 x 2-1/4 in. Bolt
DD
Lock Washer
EE
Small Flat Washer
FF
Hex Wrench
Adjustable Level
5. In case of uneven floors, floor levelers are provided at the bottom of
the vanity. If necessary, adjust floor levelers by hand to correct tilting
and/or level doors.
Backsplash Installation
6. To mount the backsplash (C) to the wall, apply a thin bead of silicone
compound (not included) to the unpolished back side and bottom of the
backsplash (C). Position backsplash (C) as shown onto vanity top (A)
and against the wall. Clean any excess silicone compound before
allowing to dry.
4
B
x 8
D
CC
x 8
x 8
5
x 1
6
C
6
ASSEMBLY INSTRUCTIONS
Removing the Drawer:
7a. Unload the contents from the drawer.
7b. Slide out the drawer as far as it will go.
7c. Press the lever down on the right-hand track and lift the lever up on
the left track to release the drawer. Pull the drawer out the rest of
the way.
D
Replacing the Drawer:
7d. Align the drawer guides with the receiving glides.
7e. Hold the receiving glides firmly and insert the drawer guide.
DD
EE
NOTE: It is normal for the drawer to close tightly the first time after it
has been removed.
DD
7f. Push the drawer in completely.
CARE AND MAINTENANCE
• Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product.
• You can clean the vanity with a gentle, non-abrasive household cleaner. Make sure to dry the wood immediately with a soft
cloth or towel.
• The engineer top can be cleaned using standard engineer cleaning agents (sold separately).
• Keep product away from direct sunlight as it may damage the finish.
Silicone
ONE-YEAR LIMITED WARRANTY
This product is warranted to the original purchaser. If there is a failure in this unit due to defects in materials or workmanship,
A
the manufacturer will repair or replace this item at our discretion without charge. Warranty is void if product has been assembled
incorrectly, misused, abused by overloading, altered in any way or damaged due to accident. This warranty is not transferable
and does not cover chipping, flaking, scratches, rust, dents, or other damages to the surfaces of this product. Responsibility
of the manufacturer is limited to repair or replacement of this product. The manufacturer is not responsible for consequential,
incidental, or other damages or losses resulting from product failure.
This warranty is in lieu of all other expressed warranties. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. This warranty gives you specific legal rights and you may
have other rights which vary from state to state.
7
