1 PREFACE

Manufacture : ELC 59 avenue des Romains 74000 ANNECY - FRANCE
Phone : +33 (0)4 50 57 30 46
Website : http://www.elc.fr
Item : TRIPLE DC STABILIZED PROGRAMMABLE POWER SUPPLY
: elc
Brand
Type : ALR3206T

2 DESCRIPTION

2.1 PRESENTATION

You just bought a TRIPLE DC STABILIZED PROGRAMMABLE POWER SUPPLY type elc ALR3206T. We thank
you and congratulate you for your good choice.
elc's company is a specialist manufacturer proposes a wide range of POWER SUPPLIES and many other
electronic test instruments : FUNCTION GENERATORS, DECADE BOXES, DIGITAL PANEL METERS...
This item has been conceived according to the European standard EN61010-1 and supplied in good condition.
This electrical instrument is intended to professionals, industrials and school users. This instructions manual
contains information and notes, which must be respected by the purchaser, in order to ensure a safe working and
to maintain the instrument in good condition.

2.2 FUNCTIONAL DESCRIPTION OF THE UNIT

This item is used in laboratories. It is designed with :
- a large graphic display,
- a sensitiv keypad,
- a compact vertical box with an handle and a cord storage integrated in the rear panel.
This item will give you satisfaction by offering many possibilities.
Fully programmable, this power supply can be controlled in several ways :
- via the front panel using the sensitive keypad
- via the isolated USB interface
- via the isolated RS485 interface
- via the isolated analogical interface (0 - 10V or the 10K potentiometer)
Two outputs of this DC power supply are regulated in voltage of 0 to 32V and current of 0 to 6A.
The third channel is regulated in voltage of 1 to 15V with 15W max power and current 3A max.
"Parallel" "Series" and "Tracking" modes allowing you to pair inside, the 1 & 2 channels of the power supply to
obtain :
Parallel : 0 to 32V and 0 to 12A
Serial : 0 to 64V and 0 to 6A
Tracking : ± 0 to 32V and 0 to 6A (mode coupled) or 2x 0 to 32V 0 to 6A (mode isolated with common
adjustment)
Several programmable functions U and I on channels 1 & 2 are accessible directly from the keypad and you will
make positive or negative ramp, up or down time, or a square wave.
An output on terminal block of channels 1 & 2 with automatic remote sensing can be enabled in mode 4 wires on
the rear panel.
The outputs can be activated or not separately or together (by the keyboard or by a dry contact on a terminal
block at the rear panel) and a "Standby" mode allows to put the power supply in energy saving.
All parameters are displayed on the graphic screen.
4000 4 361_09/22
