NAMES OF PARTS AND CONTROLS

Top and front sides
1 VOLUME knob
2 STANDBY/ON button
3 GROUP – button
GROUP + button
4 Tape operation buttons
PAUSE 8 button
STOP/EJECT § button
FF 1 button
REW ¡ button
PLAY 2 button
REC ¶ button
5 Disc door
6 PRESET DOWN button
7 PROGRAM/CLOCK SET button
1 2 3 4
REMOTE
SENSOR
9 10 11 12
5 6 7
PUSH
DISPLAY
13 14 15
8 PRESET UP button
9 TAPE button
CD/RANDOM button
BAND/TUNER button
10 REMOTE SENSOR
11 Display window
12 Casette deck
13 DISPLAY button
14 4 button
¢ button
PLAY/PAUSE 3/8 button
STOP 7 button
15 HBS/PRESET EQ button
8
4
